Background

The Asus Chromebook CM1402CM2A-DS44 is a part of Asus's CM14 series, and was designed to offer affordable and reliable computing for students, workers, and casual users. This edition was released in November of 2023 and featured a 14-inch HD anti-glare display. It is powered by the MediaTek Kompanio 520 processor, and comes with 4 GB of RAM and 64 GB of eMMC storage. Running on ChromeOS allows the device to run error free with Google Workspace and access to a widespread range of applications via the Google Play Store. It is also boasted by a long 13-15 hour battery life.

Identification

By checking the bottom of the Asus Chromebook, you will be met with the full model number and information to check to see which type of Asus CM series you are working with. Going into the systems and checking the ChromeOS can also help identify what system it is.

Technical Specifications

Display:

Size: 14.0 inches

Resolution: Full HD (1920 x 1080)

Features: Anti-glare, LED backlit, 220 nits brightness, 45% NTSC color gamut, 77% screen-to-body ratio

Performance:

Processor: MediaTek Kompanio 520, Octa-core, up to 2.05 GHz

Graphics: ARM Mali-G52 MC2

Memory: 4 GB LPDDR4X

Storage: 64 GB eMMC

Battery & Power:

Battery: 2-cell, 42WHrs lithium-ion

Battery Life: Up to 15 hours

Charger: 45W USB-C AC Adapter

Connectivity:

Wi-Fi: Wi-Fi 6 (802.11ax)

Bluetooth: Bluetooth 5.3

Ports: 2 x USB-C Gen1, 1 x USB-A 3.2 Gen 1, 1x 3.5mm combo audio jack, 1 x microSD card reader

Build & Design:

Keyboard: Chiclet-style, spill-resistant, 1.5mm key travel

Webcam: 720p HD with privacy shutter

Durability: MIL-STD 810H military-grade certified

Dimensions: 32.45 x 22.67 x 1.83 cm (12.78" x 8.93" x 0.72")

Weight: 3.20 lbs (1.45 kg)

Operating System:

OS: ChromeOS

Android App Support: Yes, via Google Play Store

Additional Features:

Hinge: 180-degree lay-flat design

Antimicrobial Protection on keyboard, touchpad and palm rest

Source: ASUS Chromebook CM14 Spec List
