Battery
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background
The HP Notebook 15-db0015dx was released in 2018 as an easy to use, affordable, daily driver for completing tasks like homework, browsing the internet, and watching videos. It has several features including a CD tray, 3 USB ports, an HDMI port, an SD card insert, and front facing camera. It has a 15.6 inch screen with a large central touch-pad and a number keypad to the right of the keyboard. It weighs in at 1.97 kg and is about 2.25 cm thick.
Identification
The HP 15-db0015dx is an HP 15 Series Notebook that can be identified with the product number 5ZC06UA.
Specifications
Hardware
- Product name: HP Notebook - 15-db00015dx
- Product number: 5ZC06UA
- CPU: 2.6 GHz AMD A6-9225 Processor (up to 3.0GHz burst speed)
- Memory, standard: 4 GB DDR4 1866 MHz SDRAM (1 x 4GB)
- Storage: 1TB - HDD
- Video Graphics: AMD Radeon ™ R4 Graphics, Integrated
- Display: 15.6” Diagonal HD SVA BrightView WLED-backlit
- Minimum dimensions (W x D x H): 37.6 x 24.6 x 2.25 cm
- Weight: 1.97 kg
- Wireless connectivity: Realtek RTL8723DE 802.11b/g/n (1x1) and Bluetooth® 4.2 combo
- Power supply type: 45 W AC power adapter
- Battery type: 3-cell, 41 Wh Li-ion
- External ports: 1 HDMI 1.4b; 1 headphone/microphone combo; 1 RJ-45; 1 USB 2.0; 2 USB 3.1 Gen 1 (Data transfer only)
- Webcam: HP Webcam with integrated digital microphone
- Audio features: Stereo speakers
Software
- Operating system: Windows 10 Home in S mode
- HP apps: HP Support Assistant; HP BIOS Protection
- Pre-installed software: Netflix
Source: HP Notebook - 15-db00015dx Product Specifications
