Introduction
Are you having problems with the touchpad on your PSKONTORORA LBER-P4-05, such as it not responding to any input? Well not to worry, this easy-to-follow guide will allow you to check what is going on within the controller.
-
-
Use blunt tweezers to pull the white battery motherboard connector directly out of its port.
-
Gently peel the battery off of the motherboard.
-
-
-
Use tweezers to disconnect the battery from the motherboard.
-
Gently lift the rumble motors out of their housings and set them beside the controller.
-
Gently peel off the battery from the motherboard, with care not to bend or puncture the battery.
-
Remove the two 7 mm Phillips #1 screws that secure the motherboard.
-
-
-
Flip up the black ZIF locking flap that secures the touchpad ribbon cable on the top-right edge of the motherboard.
-
Use tweezers or your fingers to gently disconnect the touchpad ribbon cable.
-
While pulling towards you, remove the motherboard.
-
Remove the black plate.
-
To reassemble your device, follow these instructions in reverse order.
