OnePlus 6 Speaker Replacement

Written By: Noah Matthew Axtell
  • Comments: 5
OnePlus 6 Speaker Replacement

Difficulty

Moderate

Steps

8

Time Required

25 minutes

Introduction

The OnePlus 6 smartphone might need a speaker replacement for several reasons, like water damage or wear from regular use. The internal speaker plays sound out loud when no external audio output is present. If the device will not play sound or sounds come out distorted, a speaker replacement may be required.

As this guide will help everyday users replace a part within the device, they should be aware of potential damage from using the heat gun. While working on the inside of the mobile phone, users should be careful not to damage any delicate parts.

  1. BwWikyqOk15xFAkY

    • Turn on the heat gun to a low heat and and gently heat the curved edges on the back of the phone.

    • Be careful not to overheat or melt the plastic; heat guns can get out of hand quickly!

    • Wedge the opening picks between the front and back panel and slide them around the perimeter to break the adhesive securing the back cover.

    • Repeat until the back panel is fully released.

    I used half a razor blade here

    derhagen -

    If you have a glass back cover, be careful not to pull too much or it may crack. It's better if you keep heating the area before trying to get in with the opening picks, specially around the corners.

    tottimeatter -

    I was using a hairdryer on 2/3 heat level and my phone was very hot to the touch and it still wouldn't budge a millimeter to get the plastic tools in. Any advice? I'm not sure heating it more is safe for the rest of the phone, so I'm not sure what else to do.

    Tim Harry -

  2. XGN4gblHUXuTQGur
    XGN4gblHUXuTQGur
    fGraGfd2KcDt2YZj

    • Gently lift up the back panel, with care not to damage the fingerprint sensor ribbon cable.

    Signal problem

    Ravi dhiman -

  3. M1ZIJHOo5Ef5eISa
    M1ZIJHOo5Ef5eISa
    p3NTQldcwbUQIlUN

    • Use a pair of tweezers to gently pull up on the red tab and disconnect the cable from the device.

    • Completely remove the back panel from the device.

  4. vO5s3R1cpApvt6IT
    vO5s3R1cpApvt6IT
    nDrlR4rWXw6QNwIr

    • Grip the green tab connected to the battery and pull the battery directly up and out.

    If step 3 is followed, then the back panel is removed in step 4. First photo shows back panel still attached.

    nereocystis -

  5. dilRe2hUBtdoBT46

    • Use a Phillips #000 screwdriver to remove the eight screws.

    • Carefully lift the speaker up and out of the chassis.

    • If you're completing a screen replacement, skip to Step 9.

  6. GcYoVwd4q2dJgWfQ

    • Properly orient the new speaker unit and use a Phillips #000 screwdriver to replace the eight screws removed from the previous step.

  7. I6JqxEaMpJc5IWIY

    • Place the battery back into the phone and connect it to the same port, making sure to firmly press the connection down into place.

    • Place the red cover back over the top of the port.

  8. mPup1AEYIQrV4S2N

    • Strip the existing adhesive, and place new adhesive around the entire perimeter of the back cover.

    • Replace the back cover and hold it down for about a minute to to let the adhesive set.

Conclusion

Enjoy your new speaker!
