HP 7 1800 Speaker Replacement

Written By: TMD
  • Comments: 0
HP 7 1800 Speaker Replacement

Difficulty

Difficult

Steps

4

Time Required

10 - 15 minutes

Introduction

This guide will aid you in the replacement of your HP 7 1800 speaker. It requires beginning soldering skills.

  1. DUXPN4HB5neYxC23
    DUXPN4HB5neYxC23
    SyB1LJLacMFR6bT4

    • Carefully insert a Spudger into one of the corners of the tablet.

    • Slide the Spudger along the edge popping the tabs out along the way.

    • Be careful not to break the tabs.

  2. QKDSu2Pc6nrqRxLw
    QKDSu2Pc6nrqRxLw
    QCRNuIKNCJX4nrRf
    KRAbXpceNZbnaBjA

    • Slide the Spudger under the battery to lift it off the adhesive.

    • Gently pull the cable connection from the motherboard using tweezers.

  3. uHheSMVv4BR1VXKG

    • Desolder the two leads of the speaker wire that are connected to the motherboard.

  4. LmenJbw42tQO4pTW

    • Using tweezers, gently pull the speaker off of the metal plate.

    • The speaker is held onto the metal plate with light adhesive. It will require a little force to peel off.

Conclusion

To reassemble your device, follow these instructions in reverse order.
