Battery
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background
The HP Pavilion g6-1d16dx laptop was released in 2011. The G-series was an affordable laptop with decent specifications but with the rebrand in 2011, it was included in the Pavilion series and received some upgrades in technical specifications. The most significant change was the upgraded 2.53GHz Intel Core i3-380M processor, though it is a 1st gen. It also has a lighter body compared to the G-series. It has a 15.6-inch display with standard 1,366x768-pixel resolution and is LED backlit. It includes Altec Lansing speakers but according to CNET, the sound is loud but thin. A big complaint is that the battery life is very short making it less portable. Another feature of note is it includes a DVD burner with LightScribe technology built in. The laptop came with a retail price of about $550.
Identification
The HP Pavilion g6-1d16dx is easliy identifiable by the HP logo centered below the screen, The HP Pavillion G series logo located on the top right of the keyboard, and the Pavilion G6 logo located underneath the bottom right corner of the screen. The model number can be located by removing the battery. It is located in the model number near the top right of the sticker in the battery compartment.
Specifications
Product Name: G6-1d16dx
Product Number: A6Y36UA#ABA
Microprocessor: 2.00 GHz Intel Pentium Processor B940
Microprocessor Cache: 2MB L3 Cache
Memory: 4GB DDR3 SDRAM (1 DIMM)
Memory Max: Maximum supported = 8GB
Video Graphics: Intel HD Graphics
Video Memory: Up to 1696MB
Hard Drive: 320GB 5400RPM)
Multimedia Drive: SuperMulti DVD burner
Display: 15.6-inch diagonal HD BrightView LED-backlit display (1366x768)
Network Card: 10/100 Ethernet LAN
Wireless Connectivity: 802.11b/g/n WLAN
Sound: SRS Premium Sound with Altec Lansing speakers
Keyboard: Full-size keyboard
Pointing Device: Touchpad with on/off button
External Ports:
Digital media card reader for Secure Digital and Multimedia cards
3 Universal Serial Bus (USB) 2.0
1 HDMI
1 VGA (15-pin)
1 RJ-45 (LAN)
1 Headphone-out
1 Microphone-in
Dimensions: 14.72" (L)x 9.65" (W) x 1.20" (min H)/1.43" (max H)
Weight: 5.22 lbs
Security:
Kensington MicroSaver lock slot
Power-on password
Accepts 3rd party security lock devices
Power:
65W AC adapter
6-cell 47WHr lithium-ion battery
HP Webcam with integrated digital microphone
